Description
The Ortofon OM 5E is a Moving Magnet (MM) turntable cartridge designed for balanced, distortion-free vinyl playback, featuring an elliptical stylus for accurate groove tracking and clean sound reproduction.
This cartridge fits standard 1/2" mounts and is built around Ortofon’s OM concept for tonearm matching. A removable weight plate is integrated into the mounting bracket, allowing compatibility with both standard and low-mass tonearms. With the weight plate installed, the cartridge weight is 5 g, and without it the cartridge weight is reduced to 2.5 g.
One of the key advantages of the OM 5 Series is stylus interchangeability. The OM body allows upgrading sound performance by changing the stylus without replacing the entire cartridge, supporting a wide range of replacement styli depending on system needs and budget.
Technical specifications (official)
Type: Moving Magnet (MM)
Stylus: Elliptical (r/R 8/18 µm)
Output voltage: 4 mV (1 kHz, 5 cm/sec)
Frequency response: 20 Hz – 20 kHz (+3 / -3 dB)
Channel separation: 22 dB (1 kHz)
Channel balance: 2 dB (1 kHz)
Recommended tracking force: 1.8 g
Tracking ability: 60 µm (315 Hz)
Tracking angle: 20°
Internal impedance (DC): 750 Ohm
Internal inductance: 450 mH
Recommended load resistance: 47 kOhm
Recommended load capacitance: 200–500 pF
Cartridge weight: 5 g (with weight plate) / 2.5 g (without weight plate)
Replacement stylus: Stylus 5E
